Haveli Chowk, Botad, Gujarat
- GST NO. : 24AAIFJ7309P1ZW
+91-9624614295 Call / WhatsApp |
8 Lac - 11 Lac / piece
Buy Now
| Business Type | Manufacturer, Exporter, Supplier |
| Quality | High Precision |
| Delivery time | 2-3 MOnths |
| Payment Terms | Advance |
| Click to view more | |
Product Details
Suitable For
Face Grinding Operation in bearing and automotive parts
Supply Ability
all over India and Exports
Automatic Grade
Semi Automatic
Power
10-15kw
Voltage
440V
Product Type
Duplex Grinding Machine,Vertical Spindle
Weight
1-5 Ton,2500 kg
Warranty
1 Year
Grinding Wheel Size
350 x 110 x 52 mm
Gap between Grinding wheel
30 mm
Quell Adjustment travel, each time
50 mm
Power requirement total
8.6 kw
Job Capacity
4 to 100 mm
Workpiece thickness
0.5 mm to 30 mm
Maximin Error in parallelism
0.005 mm
Maximum error in Flatness
0.005 mm
Brand Name
RADOMAK
Usage
For Face Grinding Operation
Specifications
| Grinding Wheel Diameter | ( MM ) | 350 |
| Gap between grinding wheels | ( MM ) | 1........40 |
| Quill adjustment travel , each time | ( MM ) | 50 |
| RADOMAK grinding wheel | ( MM ) | 350X50X110 |
| Power requirement total , | ( K.W.) | 8.6 |
| approx | ( H.P.) | 11.75 |
| Net Weight approx | ( K.G.) | 1200 |
| Workpiece diameter | ( MM ) | 10........100 |
| Workpiece thickness | ( MM ) | 3.....30 |
| Maximum error in Parallelism | ( MM ) | 0.005 |
| Maximum error in flatness | ( MM ) | 0.005 |
